The wire rope is classified into point contact rope (Cross Laid Rope) and linear contact rope (Parallel Laid Rope) depending on contact between wire while the contract rope which is most ideal for wire contact is developed and its usage is rapidly being spread.
Our company is also developing various types of compacted ropes and mass producing them.
No
Category
Remarks
1
High Breaking Load
Breaking load is high because the area of wire per single dimension is greater compared to regular ropes of same type.
2
Fatigue Resistance and Wear Resistance
Due to external processing, the step2 curve appears less, surface is even and wire contact to have fatigue resistance and wear resistance.
3
Low form variation
Less inner space by delicate contact of strands and has low form variation even if external pressure is high because the exterior also accomplishes contact.
4
Low damage of Drum, Sheave, Roller
Because the wire surface area contacting with Drum, Sheave and Roller is high as the surface of strand is even, the damage of these equipment is low.
